Full Details

Engine

• Model: Kubota V2003

• Type: 4-cylinder diesel

• Power: 56 HP

• Displacement: 2.0L

• Cooling: Liquid-cooled

• Fuel Capacity: 91 liters

Performance

• Rated Operating Capacity (ROC): 1,600 lbs (≈ 726 kg)

• Tipping Load: 3,200 lbs (≈ 1,452 kg)

• Operating Weight: 2,600 kg (≈ 5,752 lbs)

Hydraulics

• Standard Flow: 16.9 gpm

• High Flow (optional): 26.4 gpm

• System Pressure: 3300 psi

• Hydraulic Tank: 32 liters

Working Dimensions

• Bucket Hinge Pin Height: 2,905 mm

• Dump Height: 2,195 mm

• Reach at Max Height: ~ 700 mm

• Dump Angle: 44°

• Rollback Angle: 25°

Machine Dimensions

• Length with Bucket: 3,310 mm

• Width over Tires: 1,676 mm

• Height to Cab: 1,938 mm

• Wheelbase: 1,030 mm

• Ground Clearance: 191 mm

Travel Speed

• Standard Speed: 11.8 km/h

• High-Speed Option: 17.9 km/h

Features

• Radial-lift boom design

• Strong breakout force

• Compatible with many attachments (bucket, forks, auger, breaker, sweeper)

• Enclosed cab optional (A/C, heater)

• Simple maintenance access

• Reliable Kubota diesel engine

Best For

• Construction

• Landscaping

• Material loading

• Small site operations

• Farms & municipal work
